Overview
The PR 4100 Microplate Reader is the next-generation 8-channel absorbance microplate reader by Bio-Rad. It provides accurate, reproducible, and fast measurements and a compact and innovative design. It is controlled via a Notebook PC.
Improved Reliability
- Latest LED technology for long life and maintenance free operation
- 8-channel absorbance microplate reader for fast measurements
- Comprehensive QC function with multicheck plate
Innovative Design
- Compact footprint
- Standalone reader operated through a PC
Comprehensive Data Analysis Software
- Power data analysis with full qualitative and quantitative EIA analysis
- Full traceability
- Regulation (EU) 2017/746 and FDA 21 CFR part 11
New LIS Connectivity
- Transfer to Laboratory Information Service (LIS) for all Bio-Rad tests
- ASTM standard protocol
Specifications
Reading head: 8 measurements, 1 reference channel
Light source: 4 light-emitting (LED)
Measurement range: 0-4.0 OD
Wavelength range: 400-750 nm
Wavelength selection
Light source: 4 light-emitting (LED)
Measurement range: 0-4.0 OD
Wavelength range: 400-750 nm
Wavelength selection
- filters (wheel of 8 filters)
- Supplied: 405, 450, 492, 550, and 620 nm
- wavelength: <15 sec
- Dual wavelenght: <20 sec
- 0.000-2.000 OD: Better than ± (1.0% + 0.010 OD)
- 2.000-3.000 OD: Better than ± (1.5% + 0.010 OD)
- 0.000-2.000 OD: Better than ± (0.5% + 0.005 OD)
- 2.000-3.000 OD: Better than ± (1.0% + 0.005 OD)
- 0.000-2.000 OD: Better than ± 1.0%
- 2.000-3.000 OD: Better than ± 1.5%
Software
Operating system: Windows® 10
Software: Magellan Tracker
Software: Magellan Tracker
Size and weight
Size in mm (H x W x D): 134 x 347 x 189
Weight: 2.6 kg
Weight: 2.6 kg
Regulatory
CE-IVD & FDA 21 CFR part 11 compliant
Electrical Data
Main power input: Basic instrument with AC adapter
External power supply: 100-240 VAC: 50/60 Hz (auto-sensing), max 1.2 A
External power supply: 100-240 VAC: 50/60 Hz (auto-sensing), max 1.2 A
Languages
English, French, German, Italian, Portuguese, Spanish, Russian, Chinese
Optional accessories (sold separately)
Wide range of filters
Calibration test plate with software (Multicheck plate)
Calibration test plate with software (Multicheck plate)
